In this tutorial, you will learn how to integrate Wazuh manager with ELK stack as a unified Security Information and Event management tool. Wazuh consists of an endpoint security agent, deployed to the monitored systems, and a management server, which collects and analyzes data gathered by the agents. Wazuh can be fully integrated with the Elastic Stack, which provides a search engine and data visualization tool that allows users to navigate through their security alerts.
Integrate Wazuh Manager with ELK Stack
There are different deployment methods of how you can integrate Wazuh manager with ELK stack:
- All-in-one deployment where all the Wazuh and ELK components are installed on a single node. Suitable for testing or small working environements.
- Distributed deployment where each component is installed on a separate node. Provides high availability and scalability and hence suitable for large working environments.
This tutorial will use an all-in-one deployment method to integrate Wazuh manager with ELK stack.
Also NOTE that we are running our setup on an Debian 10 system.
Install Wazuh Server on Debian 10
Create Wazuh Repository on Debian 10
apt install curl apt-transport-https unzip wget libcap2-bin software-properties-common lsb-release gnupg2
curl -s https://packages.wazuh.com/key/GPG-KEY-WAZUH | gpg --dearmor > /etc/apt/trusted.gpg.d/wazuh.gpgecho "deb https://packages.wazuh.com/4.x/apt stable main" | tee /etc/apt/sources.list.d/wazuh.list
Update the package information:
apt update
Install Wazuh server on Debian 10
Next, install Wazuh manager on Debian 10.
apt install wazuh-manager
Once the installation is complete, you can start and enable Wazuh-manager to run on system boot;
systemctl enable --now wazuh-manager
Install ELK/Elastic Stack on Debian 10
If you want, you can deploy the OpenDistro ELK, but in this setup, we are using the “usual” ELK/Elastic stack.
According to Wazuh compatibility matrix, ELK/Elastic stack 7.14.2 is compatible with current version (as of this writing) of Wazuh-manager v4.2.6.
Hence, install ELK/Elastic 7.14.2 on Debian 10 as follows;
Create Elastic repository on Debian 10;
wget -qO - https://artifacts.elastic.co/GPG-KEY-elasticsearch | gpg --dearmor > /etc/apt/trusted.gpg.d/elastic.gpg
echo "deb https://artifacts.elastic.co/packages/7.x/apt stable main" | sudo tee /etc/apt/sources.list.d/elastic-7.x.list
apt update
Install Elastic Stack on Debian 10
Next, install ELK stack v7.14.2 on Debian 10. Basically, we only need Kibana, Elasticsearch and Filebeat in this case.
apt install elasticsearch=7.14.2 kibana=7.14.2 filebeat=7.14.2
Configure Elasticsearch
With the default settings, Elasticsearch can run well. However, in this setup, we will adjust some few Elasticsearch settings like JVM maximum and minimum memory settings, discovery type…
To update the JVM min and max memory setup, simply open the jvm.options configuration file and update the value of the Xmx and Xms based on the available memory on your server.
vim /etc/elasticsearch/jvm.options.d/jvm.custom.options
It is set to 512mb in this setup
# Xms represents the initial size of total heap space # Xmx represents the maximum size of total heap space -Xms512m -Xmx512m
Also, if you are running a single node ES, just like in our setup, then you need to define it in the Elasticsearch configuration file by adding the line discovery.type: single-node.
Note, this change is only required if you are configuring Elasticsearch to listen on an interface IP rather than the loopback address.
echo "discovery.type: single-node" >> /etc/elasticsearch/elasticsearch.yml
The above configs are just enough for now.
Start and enable Elasticsearch to run on system boot;
systemctl enable --now elasticsearch
Configure Kibana
Define the IP address in which Kibana will bind to, localhost by default. Replace the IP address accordingly.
sed -i 's/#server.host: "localhost"/server.host: "192.168.59.12"/' /etc/kibana/kibana.yml
Configure Kibana to connect to Elasticsearch, By default, Kibana connects to Elasticsearch on localhost URL. In our setup, Elasticsearch is bound to localhost address.
ss -altnp | grep 9200
LISTEN 0 128 [::ffff:127.0.0.1]:9200 *:* users:(("java",pid=8580,fd=258))
LISTEN 0 128 [::1]:9200 [::]:* users:(("java",pid=8580,fd=257))
Otherwise, uncomment the line, elasticsearch.hosts: ["http://localhost:9200"] and replace the address accordingly.
Start and enable Kibana to run on system boot;
systemctl enable --now kibana
Integrate Wazuh Manager with ELK Stack
Install Wazuh Manager Kibana App
Run the command below to install Wazuh manager/server for Kibana App.
chown -R kibana: /usr/share/kibana/plugins
Ensure the plugin version to install is compatible with currently installed version of ELK stack.
sudo -u kibana /usr/share/kibana/bin/kibana-plugin install https://packages.wazuh.com/4.x/ui/kibana/wazuh_kibana-4.2.6_7.14.2-1.zip
Sample output of the installation;
Attempting to transfer from https://packages.wazuh.com/4.x/ui/kibana/wazuh_kibana-4.2.6_7.14.2-1.zip Transferring 34175540 bytes.................... Transfer complete Retrieving metadata from plugin archive Extracting plugin archive Extraction complete Plugin installation complete
Create Wazuh Kibana data directory and set the ownership to kibana user.
mkdir /usr/share/kibana/data
chown -R kibana: /usr/share/kibana/data
Restart Kibana;
systemctl restart kibana
Configure Filebeat
Wazuh uses Filebeat to collect its data and forward to Elasticsearch search engine.
Make a backup of the default configuration file and replace it with the following configs.
mv /etc/filebeat/filebeat.{yml,orig}
cat > /etc/filebeat/filebeat.yml << 'EOL'
output.elasticsearch:
hosts: ["localhost:9200"]
setup.template.json.enabled: true
setup.template.json.path: '/etc/filebeat/wazuh-template.json'
setup.template.json.name: 'wazuh'
setup.ilm.overwrite: true
setup.ilm.enabled: false
filebeat.modules:
- module: wazuh
alerts:
enabled: true
archives:
enabled: false
logging.level: info
logging.to_files: true
logging.files:
path: /var/log/filebeat
name: filebeat
keepfiles: 7
permissions: 0644
EOL
Install Filebeat Wazuh Module:
wget -qO- https://packages.wazuh.com/4.x/filebeat/wazuh-filebeat-0.1.tar.gz | tar -xz -C /usr/share/filebeat/module/
Download Wazuh alerts Elasticsearch template:
wget -O /etc/filebeat/wazuh-template.json https://raw.githubusercontent.com/wazuh/wazuh/4.2/extensions/elasticsearch/7.x/wazuh-template.json
Test Filebeat config;
filebeat test config
Config OKTest Filebeat Elasticsearch output;
filebeat test output
elasticsearch: http://localhost:9200...
parse url... OK
connection...
parse host... OK
dns lookup... OK
addresses: 127.0.0.1, ::1
dial up... OK
TLS... WARN secure connection disabled
talk to server... OK
version: 7.14.2
Restart Kibana, Elasticsearch, Filebeat ans Wazuh-manager
systemctl restart elasticsearch kibana filebeat wazuh-manager
Checking the status of each service;
systemctl status elasticsearch kibana filebeat wazuh-manager
● elasticsearch.service - Elasticsearch
Loaded: loaded (/lib/systemd/system/elasticsearch.service; enabled; vendor preset: enabled)
Active: active (running) since Tue 2021-05-11 00:43:05 EDT; 2min 20s ago
Docs: https://www.elastic.co
Main PID: 10698 (java)
Tasks: 64 (limit: 2359)
Memory: 819.4M
CGroup: /system.slice/elasticsearch.service
├─10698 /usr/share/elasticsearch/jdk/bin/java -Xshare:auto -Des.networkaddress.cache.ttl=60 -Des.networkaddress.cache.negative.ttl=10 -XX:+AlwaysPreTouch -Xss1m
└─10880 /usr/share/elasticsearch/modules/x-pack-ml/platform/linux-x86_64/bin/controller
May 11 00:42:38 debian systemd[1]: Starting Elasticsearch...
May 11 00:43:05 debian systemd[1]: Started Elasticsearch.
● kibana.service - Kibana
Loaded: loaded (/etc/systemd/system/kibana.service; disabled; vendor preset: enabled)
Active: active (running) since Tue 2021-05-11 00:42:33 EDT; 2min 52s ago
Main PID: 10666 (node)
Tasks: 11 (limit: 2359)
Memory: 285.9M
CGroup: /system.slice/kibana.service
└─10666 /usr/share/kibana/bin/../node/bin/node /usr/share/kibana/bin/../src/cli/dist
May 11 00:43:15 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:15Z","tags":["info","plugins","crossClusterReplication"],"pid":10666,"message":"Your basi
May 11 00:43:15 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:15Z","tags":["info","plugins","watcher"],"pid":10666,"message":"Your basic license does n
May 11 00:43:15 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:15Z","tags":["info","plugins","monitoring","monitoring","kibana-monitoring"],"pid":10666,
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["error","elasticsearch","data"],"pid":10666,"message":"[version_conflict_eng
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["error","elasticsearch","data"],"pid":10666,"message":"[version_conflict_eng
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["error","elasticsearch","data"],"pid":10666,"message":"[version_conflict_eng
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["error","elasticsearch","data"],"pid":10666,"message":"[version_conflict_eng
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["listening","info"],"pid":10666,"message":"Server running at http://192.168.
May 11 00:43:16 debian kibana[10666]: {"type":"log","@timestamp":"2021-05-11T04:43:16Z","tags":["info","http","server","Kibana"],"pid":10666,"message":"http server running
● filebeat.service - Filebeat sends log files to Logstash or directly to Elasticsearch.
Loaded: loaded (/lib/systemd/system/filebeat.service; disabled; vendor preset: enabled)
Active: active (running) since Tue 2021-05-11 00:42:33 EDT; 4min 32s ago
Docs: https://www.elastic.co/products/beats/filebeat
Main PID: 10667 (filebeat)
Tasks: 8 (limit: 2359)
Memory: 31.6M
CGroup: /system.slice/filebeat.service
└─10667 /usr/share/filebeat/bin/filebeat --environment systemd -c /etc/filebeat/filebeat.yml --path.home /usr/share/filebeat --path.config /etc/filebeat --path.d
May 11 00:42:33 debian systemd[1]: Started Filebeat sends log files to Logstash or directly to Elasticsearch..
● wazuh-manager.service - Wazuh manager
Loaded: loaded (/lib/systemd/system/wazuh-manager.service; enabled; vendor preset: enabled)
Active: active (running) since Tue 2021-05-11 00:48:02 EDT; 8s ago
Process: 11127 ExecStart=/usr/bin/env ${DIRECTORY}/bin/ossec-control start (code=exited, status=0/SUCCESS)
Tasks: 100 (limit: 2359)
Memory: 277.5M
CGroup: /system.slice/wazuh-manager.service
├─11179 /var/ossec/framework/python/bin/python3 /var/ossec/api/scripts/wazuh-apid.py
├─11219 /var/ossec/bin/ossec-authd
├─11233 /var/ossec/bin/wazuh-db
├─11256 /var/ossec/bin/ossec-execd
├─11271 /var/ossec/bin/ossec-analysisd
├─11315 /var/ossec/bin/ossec-syscheckd
├─11328 /var/ossec/bin/ossec-remoted
├─11360 /var/ossec/bin/ossec-logcollector
├─11380 /var/ossec/bin/ossec-monitord
└─11407 /var/ossec/bin/wazuh-modulesd
May 11 00:47:53 debian env[11127]: Started wazuh-db...
May 11 00:47:54 debian env[11127]: Started ossec-execd...
May 11 00:47:55 debian env[11127]: Started ossec-analysisd...
May 11 00:47:56 debian env[11127]: Started ossec-syscheckd...
May 11 00:47:57 debian env[11127]: Started ossec-remoted...
May 11 00:47:58 debian env[11127]: Started ossec-logcollector...
May 11 00:47:59 debian env[11127]: Started ossec-monitord...
May 11 00:48:00 debian env[11127]: Started wazuh-modulesd...
May 11 00:48:02 debian env[11127]: Completed.
May 11 00:48:02 debian systemd[1]: Started Wazuh manager.
Accessing Kibana Web Interface
You can now access Kibana via the url http://<server-IP-or-hostname>:5601.
Under the Kibana menu section, you should be able to see Wazuh App.
When you click on the App, it takes you the modules page;
And there you go. you can now go ahead and install the agents to collect logs from your endpoints and sent them to Wazuh manager for visualization on Kibana.
That concludes our guide on how to integrate Wazuh Manager with ELK Stack.
